TRUCORE™ UPIX BARREL OPTIONS
The standard barrel option is available in dedicated diameters corresponding to B, N, and H size hole applications. These barrel options combine to cover the complete range of hole sizes from B to P with size-specific inner tube adapters and check valve systems.
The ONE option is available in a single N size barrel configuration but can cover the complete range of hole sizes from N to P with field-replaceable grease caps, inner tube adapters, and check valve systems.
TRUCORE™ UPIX AUDIT DATA
AUDIT DATA OPTION
TruCore UPIX is now available with optional audit data export functionality to provide a complete digital record of every orientation.
Audit data-enabled handhelds are fully backwards compatible with all TruCore UPIX tools. The audit data functionality is unlocked through the charging docks featuring a USB port. Once downloaded, the data can be accessed using Microsoft Excel.
TAKE CORE. TAKE CONTROL.
Boart Longyear has a living legacy of delivering innovation in drilling technology. As a tool in Boart Longyear’s new line of instrumentation, TruCore UPIX is supported by a hands-on team of experts with professional backgrounds in drilling, geology, and engineering.
TRUCORE UPIX IS OFFERED IN SIZES B THROUGH TO P
5 REASONS TO TAKE CONTROL WITH TRUCORE UPIX
TruCore UPIX provides accurate orientation and dip data that geologists, drillers, and engineers rely on.
Core orientation is easier with TruCore UPIX. There is no need to disassemble the core barrel to obtain an orientation mark.
Full-length extended outer tubes eliminate the need for extensions, reducing the number of joints in the drill string for improved reliability.
Improve driller health and safety with reduced manual handling time and a better ergonomic position when reading core orientations.
Make faster decisions on the direction of your hole with more frequent dip measurements.
|BQ™, BQTK, NQ, NQ2, NQ3, NTW, HQ, HQ3, HTW, PQ, PQ3, LTK60
|0° to ±85° dip
|41.4 MPa (6000psi)
|2 x TruCore™ UPIX tools
|2 x Spare batteries
|O-ring replacement kit
|User Guide and Certificate of Conformance
|2 x Inner tube adapters with check valve installed
|Handheld charging deck
|TruCore™ UPIX Handheld unit
|Power pack with electrical cord
|Note: ONE kit configurations may include multiple sizes within the kit or shipped separately to cover the sizes requested.
